BEAUREGARD: Our Classic

Literally and figuratively the classic in our range.

The BEAUREGARD is a timeless design that is equipped with the current modern techniques.

Available with a beautiful copper housing or coated in stainless steel.
By choosing a warm light color (2200, 2400, 2700K) and possibly a beaded shade, you get a rustic light image that enhances the atmosphere of a historic city center.

The Beauregard can be used as a post top, as a pendant, but also on a matching wall arm.

APPLICATIONS

Icon cycle-paths

Cycle paths

Icon Footpaths

Footpaths

Icon Residential streets

Residential streets

Icon Residence areas

Residence areas

APPLICATIONS

• Mounting: suspended et post top
• Recommended heights: 3 to 8 m
• Urban streets, pedestrians, cycle paths, squares

DESCRIPTION

  • Four-legged holder in injected aluminium
  • Fitting and dome in stainless steel or copper (option)
  • Embellishment screws made of brass
  • 6 bowls :
    - PPC: flat clear polycarbonate bowl*
    - PCC: shallow clear polycarbonate bowl
    - PCS: shallow structured polycarbonate bowl - PHC: deep clear polycarbonate bowl
    - PHS: deep structured polycarbonate bowl
    - PHO: deep opaline polycarbonate bowl

    *Only for luminaire with BLS module

  • Stainless steel version: Polyester powder coating, standard colour RAL 9005. Other colours on request
  • Copper fitting (option): polyester varnish
  • IP 66
  • IK 10
  • Class I or II
  • SOMLED 1 module or BLS STRIPS
  • Colour temperature: 4000 K and 3000 K

CITIZEN REFERENCE POINTS

• Materials used: Steel 47%, Aluminium 38%, Other 10%, Plastic 5%
• Complies with the RoHS directive
• High recyclability rate

WATERPROOFING

• IP 65 waterproofing in accordance with the standard EN 60 529
• Extruded silicone gasket
• Breathing system with activated carbon filter

MECHANICAL INTERFACES

  • Post top luminaire: gliding hole for Ø 27 pdg (G3/4”) (see page 278 - K) Optional post top Ø 27 pdg (G3/4”) for Ø 60/62 mm pole
  • Suspended luminaire: threaded swivel joint Ø 27 pdg (G3/4”)

DIMENSIONS

Width: 380mm Height: 720mm
Weight: 10kg Scx: 0,13 / 0,20m2

CONNECTIVITY

• 0-10V
• DALI
• SR+Zhaga (D4I)
• Bluetooth
